Hydraulic and pneumatic conveyor belt vulcanizer

Product Description Water And Air Pressure Conveyor Belt Vulcanizing Press Machine  Application of rubber belt vulcanizer :  1. Steel Cord Belt Intermediate Rubber is an uncured rubber for hot vulcanized belt splicing. 2. It is designed to use as an

Featured Products

Product Description

Water And Air Pressure Conveyor Belt Vulcanizing Press Machine


Application of rubber belt vulcanizer :



1. Steel Cord Belt Intermediate Rubber is an uncured rubber for hot vulcanized belt splicing.



2. It is designed to use as an inter-core cord rubber replacement material in splicing steel cord conveyor belts or a tie gum in fabric belts.


3. The material is designed to bond to cured intercore rubber and wire cords in all standard grade steel cord conveyor belts, as well as fabric belt cured skim rubber and general bond improvement material for general grade fabric conveyor belts.



The ZLJ sectional has uniform pressure bag and aluminum/steel bolt and high grade aluminum platens and beams with restraining system set as standard. Such belt splicing system designed to be portable and easy to set-up and remove from the site.

We can manufacture to all sizes and pressure up to 200 psi required for different fabric belts and steelcord belts.

Technical Parameters:
* Vulcanizing temperature: 145ºC (adjustable 0~200ºC)
* Temperature-rising time (from normal temp to vulcanizing temp):≤50 mins(around 25~30 mins normally)
* Improved cooling system: using pressure pump for cooling:only 5mins (cooling from 145 to 75 degrees)
* Belt width: from 650mm to 3000mm 200PSI Almex alike Uniform Pressure Bag for Conveyor Belt Press
* Degree of the heating platen:22 °/17 °/ 20 ° (rectangle and other degree is optional)
* Waterbag/ air pressure Press for 100PSI, 200PSI etc.
* Surface pressure for textile and steel cord belts, Up to 1.8Mpa.
* 100 p.s.i. (7 kg/cm sq.) units suitable for splicing fabric ply belting
* 200 p.s.i. (14 kg/cm sq.) units suitable for splicing steel cord conveyor belting
* Customization/OEM:Different heating platen size and combination



The dimension and shape of the machine can be customized by your requirements.

ALMEX STYLE design available

Model

Belt width(mm)

Total Power(kw)

Dimensions

(L*W*H mm)

Net Weight

(kg)

Max weight of single

Component after separation(kg)

ZLJ-650*830

650

9.5

1370*830*630

430

45

ZLJ-650*1000

10.8

1370*1000*630

500

66

ZLJ-800*830

800

11.2

1520*830*630

535

70

ZLJ-800*1000

13.5

1520*1000*630

575

79

ZLJ-1000*830

1000

14.1

1720*830*630

595

82

ZLJ-1000*1000

15.7

1720*1000*630

620

95



Water and Air Pressure Conveyor Belt Vulcanizing Press Machine





The dimension and shape of the machine can be customized by your requirements.

ALMEX STYLE design available

Model

Belt width(mm)

Total Power(kw)

Dimensions

(L*W*H mm)

Net Weight

(kg)

Max weight of single

Component after separation(kg)

ZLJ-650*830

650

9.5

1370*830*630

430

45

ZLJ-650*1000

10.8

1370*1000*630

500

66

ZLJ-800*830

800

11.2

1520*830*630

535

70

ZLJ-800*1000

13.5

1520*1000*630

575

79

ZLJ-1000*830

1000

14.1

1720*830*630

595

82

ZLJ-1000*1000

15.7

1720*1000*630

620

95

ZLJ-1600*830

1600

21.5

2320*830*800

1270

120

ZLJ-1600*1000

22.3

2320*1000*800

1460

146

ZLJ-2000*830

2000

27.2

2720*830*950

1760

154

ZLJ-2000*1000

30.0

2720*1000*950

1860

182


OUR PORDUCT
Water and Air Pressure Conveyor Belt Vulcanizing Press Machine



STANDARD EXPORT PACKAGE

Water and Air Pressure Conveyor Belt Vulcanizing Press Machine
Our Services

ANTAI is the leading manufacturer of conveyor belt vulcanizing equipment. ANTAI has been offering unique Sectional Vulcanizing Systems that provide strong, long-lasting splices, for over 27 years in china.


The Unique and Innovative belt splicing system designed to be portable and offer maximum versatility in splicing all types and sizes of conveyor belting. It's intelligent, modular design and vast array of unique operating features, can handle all types of belt designs in every conveyor application.
The ZLJ series belt vulcanizing machine (hereinafter referred to as vulcanizer) is an electrothermal type vulcanizing device used for on-site splicing of conveyor belts. With the advantages of advanced technology, compact structure and convenient usage, it's used for the vulcanized jointing of the belts mixed with canvas, nylon, steel cord, etc., and it's also suitable for the flame retarded, corrosion proof and other special belts. The application area of this kind of vulcanizer is very wide, it can be used in metallurgy, mining, power plant, port and wharf, building material factory, chemical factory and so on.


The Sectional vulcanizer offers equipment, which is portable and easy to set-up and remove from the site. It has accurate control and indication uniform temperature due to the unique element design and uniform pressure over the entire splice area. Components in this model are lightweight and easy to


Water and Air Pressure Conveyor Belt Vulcanizing Press Machine

FAQ

01) Q: Normal delivery time?
A: We have table produce line, hot sale products normally HAVE STOCK. If customized, need about 15 working days


02) Q: Will you test the machine before shipping?
A: Yes, each machine, we will install and test before shipping. And testing pressure is higher than working pressure.

03) Q: Can you print our logo or without any logo?
A: It's no problem OEM. Before order, please send us the clear document of your logo, also the authorization paper to allow us to print your logo.

04) Q: Whether can visit your workshop and to see how to process the machine?
A: No problems, you are always welcomed to visit us, before order or before shipping.If need to see how to process the machines,
please inform us what type machines you want to see, we will try to prepare the similar machines ready before you come.

05) Q: What's the payment term?
A:Normally we accept T/T 30% as deposit before production, pay the rest before delivery.
We also accept VISA vis Credit Assurance, Paypal and L/C.
